Product Details
The Gamewell FCI AMM-2F is a compact Velociti Series addressable monitor module for Gamewell-FCI addressable fire alarm control panels. It provides one Style B Class B initiating device circuit for normally open dry-contact devices, allowing a connected device or group of devices to report as an addressable point on the SLC.
Key Specifications:
Type: Addressable monitor module
Core Function(s): Monitors one normally open dry-contact initiating device circuit
Loop/Protocol: Gamewell-FCI SLC; Velociti Series communication
Power: Powered by the SLC loop; .000375 amps supervisory current; .00060 amps alarm current
Circuit Configuration: One Style B Class B IDC circuit
Programmable Functions: Can be programmed for input types such as manual station, heat detector, waterflow switch, tamper switch, remote zone, system reset, system silence, system acknowledge, or drill switch
IDC Ratings: 40 ohms maximum line resistance; 47K ohm EOL resistor
Mounting: Compact module for installation inside compatible manual stations, junction boxes, or alarm initiating device mounting boxes
System Compatibility:
Compatible with Gamewell-FCI addressable series fire alarm control panels that support Velociti Series SLC devices, including E3 Series systems.
