POTTER PBA-248

Product Overview The PBA-248 is an 8-inch vibrating bell designed for fire, burglar, or general signaling applications. It delivers high decibel output while maintaining low power consumption. The bell is suitable for indoor mounting on a standard 4" (101mm) square electrical box, and can also be installed outdoors using a BBK-1 or HC-BB weatherproof backbox. The unit is UL, ULC, and FM approved for reliable signaling performance.

Key Features

- Model Number: PBA-248
- Item Number: 1808024
- Voltage: 120VAC
- Maximum Current: 0.17A
- Sound Level: Typical 94 dB @ 10 ft., Minimum 77 dB @ 10 ft.
- Size: 8" (also available in 6" and 10")
- UL, ULC, and FM approved
- Indoor or outdoor use (requires weatherproof backbox for outdoor)
- Low power consumption
- Mounts to standard 4" square electrical box (indoor) or BBK-1/HC-BB backbox (outdoor)
- Termination: 4 No. 18 AWG stranded wires
- Finish: Red powder coating
- Operating Temperature Range: -40° to 150°F (-40° to 66°C)
