Product Details
The Simplex 2099-9103 Double-action (Breakglass) Manual Pull Station is Non-Coded, Non-Addressable.
Double Action Stations featuring Breakglass activation require the operator to strike the front mounted hammer to break the glass and expose the recessed pull lever. The lever then operates as a single action station.
COMPATIBLE SIMPLEX ACCESSORIES:
— 2099-9803 Replacement breakglass (standard, English)
— 2099-9822 Replacement retaining clip for breakglass
— 2099-9828 Institutional cover kit
— 2975-9178 Red, surface mount box, sheet metal, 5-3/16” H x 4” W x 2-3/16” D (127 mm x 102 mm x 56 mm)
— 2975-9022 Red, cast aluminum surface mount box, 5” H x 3-7/8” W x 2-3/16” D (127 mm x 98 mm x 56 mm)
NOTE: B Key not included. B Key sold separately.
