POTTER CS-24WRW

Product OverviewThe CS-24WRW is a 24VDC colored-lens notification appliance designed for reliable visual and audible signaling. It offers field-selectable candela settings of 15, 30, 60, 75, and 110, along with multiple tone options including chime, whoop, mechanical, and 2400Hz. The device maintains a minimum flash rate of 1Hz across the entire voltage range and supports synchronization using Gentex protocols or the AVSM Sync Module. It includes a universal die-cast mounting bracket featuring the Super-Slide design for quicker pre-wire and supervision testing, plus the Checkmate feature for instant voltage verification.

Key Features- Field-selectable candela output: 15, 30, 60, 75, 110
- Available in amber, blue, green, and red lens colors
- Super-Slide bracket for simplified installation and supervision testing
- Checkmate feature for instant voltage confirmation
- Compatible with AVSM or Gentex synchronization
- Audible silence feature while strobe continues to flash
- Selectable tones: chime, whoop, mechanical, and 2400Hz
- Continuous or temporal 3 pattern options (temporal not available on whoop)
- Concealed locking mechanism for a clean, secure installation
Specifications:

- Operating Voltage: 24VDC nominal (16–33VDC)
- Indoor Use Only: 32°F to 120°F (0°C to 49°C)
- Dimensions: 5" H × 4.5" W × 2.5" D
- Wiring Terminals: Accept 18–12 AWG conductors
- Mounting Options: Single gang, double gang, or 4" square backbox; AVBB surface mount compatible
- Shipping Weight: 1.05 lbs.
